Product Details:
|
|
| Place of Origin: | China |
|---|---|
| Brand Name: | JRLite OEM/ODM |
| Certification: | UL / TUV / CE / ROHS / REACH |
| Model Number: | LEDLINE FLEX SIDE WTH-65 |
|
Payment & Shipping Terms:
|
|
| Minimum Order Quantity: | 1PC |
| Price: | Negotiable |
| Packaging Details: | On ESD Bag,on shipping box, without LOGO. Standard 5Mtr/reel, different lengths can be offered if needed. |
| Delivery Time: | 3-4 weeks after payment |
| Payment Terms: | D/P T/T Paypal |
| Supply Ability: | IP20 LED strip 50000m per day |
|
Detail Information |
|||
| Model: | LEDLINE FLEX SIDE WTH-65 | IP Grade: | IP68 |
|---|---|---|---|
| LED Color: | Cold White | Power(W/M): | 5W/M,10W/M,15W/M |
| Life span: | >54000hrs | Max. Run Length: | 16M@10w |
| Certification: | CE, RoHS, Reach, UL | Storage Temperature: | -25℃ ～ +60℃ |
| High Light: | neon flexible led strip Side Bend,6500k flexible neon led strip light,neon flexible led strip JRLite |
||
Product Description
Cold White 6500k Polyurethane Neon Flexible LED Strip Side Bend DC24V IP68 Ra93
Quick Detail:
· Size 12x20mm(WxH) / 0.47" x 0.79"(WxH)
· UV-resistance(no yellowish)
· Lumileds LED 2Step
· 120º beam projection
· Maximum run length 16M@10W
· IP68 rating
· Cable entry directions: Front/Side/Bottom cable entry
· CE, RoHS, Reach, UL compliant
· Life Span >54000H
· 5 Year Warranty
· Customized cable length as you need
· Suitable for underwater project
Description:
-LEDLINE FLEX SIDE WHT, DC24V. Cross section size 12mm x 20mm / 0.47" x 0.79" (W x H), which is horizontal bending with radius of 150mm / 5.9".
-Thanks to full Polyurethane coating, it is IP68 protected, UV resistant, solvents resistant and saltwater temporary immersion.
-2-Step MacAdam bin and dot free lighting effect guarantee the most excellent performance for indoor & outdoor applications.
Specifications:
| Tech Date | |
| Model | LEDLINE FLEX SIDE WTH-65 |
| LED Type | Lumileds 2835 |
| Beam Angle | 120° |
| LED PIN Temperature | Max.65℃ |
| Storage Temperature | -25℃ ～ +60℃ |
| Life span | >54000hrs |
| Certification | CE, RoHS, Reach, UL |
| IP Grade | IP68 |
| Warranty | 5 Years |
| Max. Run Length | 16M@10w |
| CRI | Ra93 |
| LED Color | Cold white |
| Voltage | DC24V(23.5Vmin, 24.5Vmax) |
| Color Temperature | 6500K |
| Power(W/M) | 5W/M,10W/M,15W/M |
Datasheet : LEDLINE FLEX SIDE WHT.pdf
Notices:
1. Please light it up for a quick check before installation.
2. Bending diameter of LEDLINE FLEX SIDE WHT is 300mm, do not bend to side direction, or bend too sharp or twist. If bend it wrongly, PCB inside will be damaged and the lighting fixture will not turn on.
3. During installation, please make sure there are at least two workers to cooperate together and strictly follow the instruction manuals.
4. Warranty: All LED light are warranted to be free from defects in product itself for 5 years from the date of purchase. This warranty does not cover failures due to abuse, misuse, improper handling, act of nature, negligence, normal wear, accidental damage, modifications or repairs made by the purchaser or incorrect voltage conditions.
Applications:
-Protected against water, dirt and corrosion and its high quality will last a lifetime.
-Designed for professional outdoor lighting, it is an ideal match solution for all high-quality applications.
-Facade lighting, yacht lighting and landscape lighting.
FAQ:
Commercial CE RoHS Reach UL Certificate Indoor IP20
Q1. Can I have a sample order for led light?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q2. What about the lead time?
A: 2-4 weeks after payment.
Q3. Do you have any MOQ limit for led light order?
A: Low MOQ, 1pc for sample checking is available.
Q4. How to deal with the faulty?
A: All LED strip are warranted to be free from defects in product itself for 3 years from the date of purchase.
This warranty does not cover failures due to abuse, misuse, improper handling, act of nature, negligence, normal wear, accidental damage, modifications or repairs made by the purchaser or incorrect voltage conditions.
