Product Details:
|
|
| Place of Origin: | China |
|---|---|
| Brand Name: | JRLite OEM/ODM |
| Certification: | UL / TUV / CE / ROHS / REACH |
| Model Number: | LEDLINE FLEX MINI WTH |
|
Payment & Shipping Terms:
|
|
| Minimum Order Quantity: | 1PC |
| Price: | Negotiable |
| Packaging Details: | On ESD Bag,on shipping box, without LOGO. Standard 5Mtr/reel, different lengths can be offered if needed. |
| Delivery Time: | 3-4 weeks after payment |
| Payment Terms: | D/P T/T Paypal |
| Supply Ability: | IP20 LED strip 50000m per day |
|
Detail Information |
|||
| Model: | LEDLINE FLEX MINI WTH | LED Type: | Lumileds 2835 |
|---|---|---|---|
| Life span: | >54000hrs | Color Temperature: | 2700K-6000K |
| Power: | 5W/M;10W/M | Voltage: | DC24V(23.5Vmin, 24.5Vmax) |
| Max. Run Length: | 12M | Unit Cut: | 41.67mm |
| High Light: | 4000k led flexible neon strip,DC24V flexible neon light rope,led flexible neon strip 10mm x 10mm |
||
Product Description
Description:
- LEDLINE FLEX MINI WHT, DC24V. Cross section size 10mm x 10mm / 0.39" x 0.39" (W
x H), 3 side emitting, which is vertical bending with radius of 75mm / 2.95".
- Thanks to full Polyurethane coating, it is IP67 protected, UV resistant, solvents resistant and
saltwater temporary immersion.
- 2-Step MacAdam bin and dot free lighting effect guarantee the most excellent performance for indoor & outdoor applications.
Specifications:
| Tech Date | |
| Model | LEDLINE FLEX MINI WTH |
| LED Type | Lumileds 2835 |
| Beam Angle | 120° |
| LED PIN Temperature | Max.65℃ |
| Storage Temperature | -25℃ ～ +60℃ |
| Life span | >54000hrs |
| Certification | CE, RoHS, Reach, UL |
| IP Grade | IP67 |
| Warranty | 5 Years |
| Max. Run Length | 12M@10w;19M@5W |
| CRI | Ra90 |
| Voltage | DC24V(23.5Vmin, 24.5Vmax) |
| Color Temperature | 2700K-6000K |
| Power(W/M) | 5W/M,10W/M |
Download datasheet: LEDLINE FLEX MINI WHT.pdf
Notices:
1. Please light it up for a quick check before installation.
2. Bending diameter of LEDLINE FLEX MINI is 150mm, do not bend to side direction, or bend too sharp or twist. If bend it wrongly, PCB inside will be damaged and the lighting fixture will not turn on.
3. During installation, please make sure there are at least two workers to cooperate together and strictly follow the instruction manuals.
4. Warranty: All LED light are warranted to be free from defects in product itself for 5 years from the date of purchase. This warranty does not cover failures due to abuse, misuse, improper handling, act of nature, negligence, normal wear, accidental damage, modifications or repairs made by the purchaser or incorrect voltage conditions.
Applications:
- Protected against water, dirt and corrosion and its high quality will last a lifetime.
- Designed for professional outdoor lighting, it is an ideal match solution for all high-quality applications.
- Facade lighting, yacht lighting and landscape lighting.
FAQ:
Q1. Are you a manufacturer?
A: Yes, we have our own factory and professional engineers to meet your any requirements. Welcome you to visit our factory.
Q2. OEM OR ODM accepted?
A: Yes,we can do OEM & ODM,logo on the light or package both are available.
Q3. Is it possible to visit the factory?
A: Of course, we welcome customers to experience our production equipment and standard production environment.
Q4. What are your payment terms?
A: 100% Payment before production or 30% deposit+ 70% before shippment(The latter requires a single payment of more than $10,000)
