Product Details:
|
|
| Place of Origin: | China |
|---|---|
| Brand Name: | JRLite OEM/ODM |
| Certification: | UL / TUV / CE / ROHS / REACH |
| Model Number: | LFSM-35 |
|
Payment & Shipping Terms:
|
|
| Minimum Order Quantity: | Negotiable |
| Price: | Negotiable |
| Packaging Details: | On ESD Bag,on shipping box, without LOGO. Standard 5Mtr/reel, different lengths can be offered if needed. |
| Delivery Time: | 3-4 weeks after payment |
| Payment Terms: | D/P T/T Paypal |
| Supply Ability: | IP20 LED strip 50000m per day |
|
Detail Information |
|||
| Model: | LEDLINE FLEX SINI 3500K | LED Type: | Lumileds 2835 |
|---|---|---|---|
| Life span: | >54000hrs | Certification: | CE, RoHS, Reach, UL |
| IP Grade: | IP68 | LED Color: | Warm White |
| Voltage: | DC24V(23.5Vmin, 24.5Vmax) | Color Temperature: | 3500K |
| High Light: | IP68 neon light warm white,waterproof led strip lights 3500K,8W neon light warm white |
||
Product Description
Main Feature:
Quick Detail:
· Size 6.5mm x 12mm / 0.26" x 0.47" (W x H)
· UV-resistance(no yellowish)
· Underwater application
· Lumileds LED
· 120º beam projection
· Maximum run length 5M@8W/m
· IP68 rating
· Cable entry directions: Front cable entry
· CE, RoHS, Reach, UL compliant
· Life Span >54000H
· 5 Year Warranty
Description:
- LEDLINE FLEX SINI WHT, DC24V. Cross section size 6.5mm x 12mm / 0.26" x 0.47" (W x H), which is horizontal bending
with radius of 30mm / 1.18".
Specifications:
| Model | LEDLINE FLEX SINI 3500K |
| LED Type | Lumileds 2835 |
| Beam Angle | 120° |
| LED PIN Temperature | Max.65℃ |
| Storage Temperature | -25℃ ～ +60℃ |
| Life span | >54000hrs |
| Certification | CE, RoHS, Reach, UL |
| IP Grade | IP68 |
| Warranty | 5 Years |
| Max. Run Length | 5M |
| CRI | Ra92 |
| LED Color | Warm white |
| Voltage | DC24V(23.5Vmin, 24.5Vmax) |
| Color Temperature | 3500K |
| Power(W/M) | 8W/m |
| Lumen | 460lm/m@8W/m |
Notices:
1. Please light it up for a quick check before installation.
2. Bending diameter of LEDLINE FLEX SINI is 60mm, do not bend to side direction, or bend too sharp or twist. If bend it wrongly, PCB inside will be damaged and the lighting fixture will not turn on.
3. During installation, please make sure there are at least two workers to cooperate together and strictly follow the instruction manuals.
Applications:
IP68 protection with full Polyurethane encapsulation. With Curved profile, perfect for shaped designs for projects.
Ideal for marine lighting, yacht lighting, cabin lighting.
Grand hotel, apartment, lobby hall.
Fits for shopping mall, flagship store, restaurant.
FAQ:
Q1. How do you ship the goods and how long does it take to arrive?
A: Ship by DHL, UPS, FedEx or TNT. It takes 3-5 days to arrive. Airline and sea shipping also optional.
Q2. How to proceed an order for led light?
A: Firstly let us know your requirements or application.
Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms the samples and places deposit for formal order.
Fourthly We arrange the production.
Q3. Is it OK to print my logo on led light product?
A: Yes. Please inform us formally before our production.
