Product Details:
|
|
| Place of Origin: | China |
|---|---|
| Brand Name: | JRLite OEM/ODM |
| Certification: | UL / TUV / CE / ROHS / REACH |
| Model Number: | ERP COVEFLEX 2835 70 WHT 6500K |
|
Payment & Shipping Terms:
|
|
| Minimum Order Quantity: | Negotiable |
| Price: | Negotiable |
| Packaging Details: | On ESD Bag,on shipping box, without LOGO. Standard 5Mtr/reel, different lengths can be offered if needed. |
| Delivery Time: | 3-4 weeks after payment |
| Payment Terms: | D/P T/T Paypal |
| Supply Ability: | IP20 LED strip 50000m per day |
|
Detail Information |
|||
| Model: | ERP COVEFLEX 2835 70 WHT 6500K | LED Type: | SMD 2835 |
|---|---|---|---|
| Power(W/M): | 4.8W/M | LM/0.5M: | 241LM |
| Efficiency(LM/W): | 100lm/w | Energy Efficiency Class: | F |
| Color Temperature: | 6500K | Voltage: | DC24V |
| LED Color: | White | ||
| High Light: | LED Neon Strip SDCM 3,WHT 6500K flexible neon led strip,LED Neon Strip ERP 2835 TUV |
||
Product Description
ERP 2835 WHT 6500K 5 Years Warranty Wide CCT Range
Description:
- One BIN Only ensures perfect color consistency.
- Long lifespan and excellent in heat dissipation.
- 5 years warranty
Quick Detail:
· ERP COVEFLEX 2835 70, DC24V.
· 70LEDs/m
· CRI80 and CRI90 optional.
· SDCM 3, One Bin Only
· Maximum run length 5M
· Unit cut is 100mm
· IP20
· CE, RoHS, Reach, UL compliant
· Life Span >54000H
· 5 Year Warranty
Specifications:
| Tech Date | |
| Model | ERP COVEFLEX 2835 70 WHT 6500K |
| LED Type | SMD 2835 |
| Beam Angle | 120° |
| LED PIN Temperature | Max.65℃ |
| Storage Temperature | -25℃ ～ +60℃ |
| Life span | >54000hrs |
| Certification | CE, RoHS, Reach, UL |
| IP Grade | IP20 |
| Warranty | 5 Years |
| Max. Run Length | 5M |
| CRI | Ra90 |
| LED Color | White |
| Voltage | DC24V(23.5Vmin, 24.5Vmax) |
| Color Temperature | 6500K |
| Chromaticity Coordinates (x and y) | x=0.463 / y=0.42 |
| Power(W/M) | 4.8W/M, |
| LM/0.5M | 241lm |
| Efficiency(LM/W) | 100lm/w |
| Energy Efficiency Class | F |
Download datasheet: ERP COVEFLEX 2835 70.pdf
JRLite Linkedin: https://www.linkedin.com/company/jrlite (Neon Supplier from China)
Notices:
1. The LED strip bending radius is 50mm. Please do not fold with sharp angle or twist the LED strip.
2. It will be likely to destroy the LED strip if exceed the maximum rated operating voltage.
3. Please do not connect the LED strip beyond the maximum connecting length.
Applications:
ERP COVEFLEX 2835 70 widely used in indoor decoration, lighting with large scale backlight. Whether in the hotel lobby, bedroom, or any indoor space, it can provide the lighting you need.
FAQ:
Commercial CE RoHS Reach UL Certificate Indoor IP20
Q1. Can I have a sample order for led light?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q2. What about the lead time?
A: 2-4 weeks after payment.
Q3. Do you have any MOQ limit for led light order?
A: Low MOQ, 1pc for sample checking is available.
Q4. How do you ship the goods and how long does it take to arrive?
A: Ship by DHL, UPS, FedEx or TNT. It takes 3-5 days to arrive. Airline and sea shipping also optional.
Q5. How to proceed an order for led light?
A: Firstly let us know your requirements or application.
Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms the samples and places deposit for formal order.
Fourthly We arrange the production.
Q6. Is it OK to print my logo on led light product?
A: Yes. Please inform us formally before our production.
Q7: Do you offer guarantee for the products?
A: Yes, we offer 3-5 years warranty to our products.
Q8: How to deal with the faulty?
A: All LED strip are warranted to be free from defects in product itself for 3 years from the date of purchase.
This warranty does not cover failures due to abuse, misuse, improper handling, act of nature, negligence, normal wear, accidental damage, modifications or repairs made by the purchaser or incorrect voltage conditions.
